Chapter 6: HSIM-W6 Configuration with QuickSET
HSIM-W6 User’s Guide 97
IP Routing Configuration
This section describes the fields in the IP Routing Configuration section of the (IP/IPX) Routing
configuration window.
Interface # — Displays an interface number assigned to an IP subnet.
Remote LAN Subnet — Displays the IP subnet assigned to the interface number.
Subnet Mask — Displays the subnet mask assigned to the interface number.
Next Hop — The Next Hop is the IP address of the IP port of the next router (in the direction of
the subnet that you are defining).
Default Route... — Displays the Default Route window. You may select one interface to be a
default route. A default route forwards all packets that are not defined in the routing table out the
interface defined in the Default Route window (Unnumbered Routing Only). To set up a default
route in Numbered Mode communication, click the Add Route... button and enter IP Subnet
000.000.000.000, and subnet mask 255.255.255.255. Then place the cursor in the Next Hop field
and enter the IP address of the router you wish to designate as the default route.
Add Route/Delete... — These buttons allow you to add or delete a route and to configure the
HSIM-W6 to forward only those packets from the specified route.
Advanced — This button allows you to access the Advanced Routing configuration window.
IPX Routing Configuration
This section describes the fields in the IPX Routing Configuration section of the (IP/IPX) Routing
configuration window.
Interface # — Displays all interface numbers that can be assigned an IPX network number.
Network # — Displays the active IPX network number assigned to an interface.
Host Map... — The IPX Host Map button takes you to the IPX Host Map window. IPX Host Map
entries are used for IPX routing in Frame Relay mode only.
Modify... — Use this button to change an entry in the IPX Routing Configuration section. Select
the interface number to modify by clicking on the tab to the left of the Interface #.
