Cabletron Systems HSIM-W6 User Manual
Page 101
Chapter 6: HSIM-W6 Configuration with QuickSET
HSIM-W6 User’s Guide
87
The following section defines the field in the Wide Area HDSL Time Slot configuration window.
Time Slots —
A full line consists of 24 Time Slots, each capable of up to 64 Kbps throughput. If
you are leasing two pair from your wiring provider, you may select all the Time Slots by clicking
the Full button. A “check mark” displays in the selected box. If you have leased one pair, click on
the Fractional button to select the first 12 Time Slots.
Once the PPP-HDSL Time Slot configuration is complete, click on Next>> in the PPP-HDSL
Time Slot configuration window and proceed to the
Bridging and Routing Configuration
section.
