Chapter 8: MIB Navigator
170 HSIM-W6 User’s Guide
MIB Navigator Screen
Access the MIB Navigator screen from the Main Menu screen using Local Management (refer to
the
Accessing Local Management section in Chapter 7 ). Using the arrow keys, highlight the
MIB NAVIGATOR option, then press ENTER. The MIB Navigator screen shown in Figure 70
appears.
Figure 70 The MIB Navigator Screen
Managing Device MIBs
The MIB Navigator lets you manage objects in the HSIM-W6 Management Information Bases
(MIBs). MIBs are databases of objects used for managing the device and determining the
HSIM-W6 configuration. The commands within the MIB Navigator allow you to view and modify
a device’s objects.
The MIB Navigator views the MIB tree hierarchy as a directory. Figure 71 shows the MIB tree
hierarchy. Each layer is numerically encoded, so that every branch group and leaf object in the
MIB is identified by a corresponding number, known as an Object Identifier (OID). This allows the
MIB Navigator to navigate through the MIB and access the manageable leaf objects.
For help with a specific command, type 'help '.
MIBNav->
090829
MIBNav-> help
Navigation Commands:
branch
dir
Is
pwd
tree
cd
get
mib2
set
ctron
grep
next
su
Other Commands:
arp
dhcp
ppp
bridge
imux
reset
circuitmap
nat
ping route
snmpget
secondIP show
snmpnext snmpset snmptree traceroute
Welcome to MIB Navigator
SPECIAL:
done, quit, or exit - Exit from the MIB Navigator.
mib2 - Change directory to MIB II (/1/3/6/1/2/1).
ctron - Change directory to Cabletron MIB (/1/3/6/1/4/1/52).
whoami
defroute
netstat
snmpbranch
help
