Chapter A: WPIM Cable Specifications
220 HSIM-W6 User’s Guide
WPIM-E1
This section provides the Cabletron Systems part number and connector specifications for the
WPIM-E1 interface cable.
Table 51 shows the WPIM-E1 connector number, cable and interface type, connector type and part
number information.
Table 52 provides WPIM-E1 network interface cable pin assignments.
Table 51 WPIM-E1 Connector Information
Connector Number Cable and Interface Type Connector Type Part Number
1
E1 RJ45 9372095
2
Table 52 Network Interface
Pin Signal
1 Receive Ring
2 Receive Tip
3 Shield Ground
4 Transmit Ring
5 Transmit Tip
6 Shield Ground
7 Not Used
8 Not Used
