Chapter C: Network Information Worksheets
230 HSIM-W6 User’s Guide
a. Used only in PPP numbered mode of addressing
b. Used only in PPP numbered mode of addressing
Remote Router Database
TCP/IP Route Addresses Remote Network’s IP
Addresses, Subnet Masks,
and Metrics Source WAN IP
Address and Subnet Mask
a
Remote WAN IP Address
and Subnet Mask
b
Remote Router Database
IPX Routes IPX Routes: Network
Number, Hop Count and
Ticks
Remote Router Database
IPX SAPs SAPs: Server Name, Server
Type, Network Number,
Node Number and Sockets
WAN Network Number
NOTE
Make one chart for each remote router in the remote router database.
Table 63 Bridging and Routing Controls
Configuration Section Item Setting
Bridging/ Routing Default Remote Bridging
Destination
TCP/IP Routing On/Off
Internet Firewall On/Off
IPX Routing On/Off
Table 62 Remote Router (Continued)
Configuration Section Item Setting
