Cabletron Systems HSIM-W6 - Manual (Page 53)

Chapter 4: Planning for HSIM-W6 ISDN Configuration
HSIM-W6 User’s Guide 39
System Settings
ISDN Settings
ISDN Line Numbers
(supplied by the service
provider)
SPIDs and Directory Numbers for one or
two ISDN B-Channels
Type of Telco switch
NTT Nippon Telegraph/Telephone
KDD Kokusai Denshin Denwa Co.
NI-1 National ISDN 1
AT&T 5ESS w/Custom Software
Northern Telecom DMS-100
NET3 European ISDN
NET3SW Swiss-Variant ISDN
System Settings
Ethernet IP Address Ethernet IP Address and
Subnet Mask Address and Subnet Mask for Ethernet
port Connection
System Settings
Ethernet IPX Network # Ethernet IPX Network
Number Network Number for Ethernet port
connection
Table 5 Configuring the Remote Router Database
Remote Router
Configuration Database
Item Description
Dial Settings
ISDN Line
ISDN Phone Numbers for one or two
ISDN B-Channels
Disconnect Timer Disconnect link on inactivity timeout
Maximum Links
Maximum number of links for bandwidth
on demand (1 or 2)
Minimum Links Minimum links (0, 1, or 2)
Threshold Percent Bandwidth utilization threshold
Bandwidth Direction Management on IN|OUT|BOTH
Dial-In Security
PAP|CHAP Security
Procedure
PAP|CHAP|NONE; minimum level of
authentication required for the remote
router.
Password/Secret
The remote router’s password used for
authentication when it dials the target
router or is challenged by the target
router.
Bridging On/Off
Bridging On/Off
Bridging from/to the remote router is On
or Off.
Spanning Tree Protocol On or Off
Table 4 Configuring System Settings (Continued)
Configuration Section Item Description
