Chapter 9: Troubleshooting
198 HSIM-W6 User’s Guide
Table 26 shows the console connection to the ASYNC port. The configuration setup for a VT100
Mode Terminal is 8 bits, No parity, 1 stop bit, and 9600 baud.
Table 25 HSIM-W6 ASYNC LED States (Console Connection Only)
LED Color State
Status (STS)
AMBER
Console connection; Data Carrier
Detect (DCD); No Data Set Ready
(DSR)
AMBER (blinking) Test mode
GREEN Modem with connection; DCD; DSR
GREEN (blinking)
Modem, no connection; DSR; No
DCD
Link (LNK)
RED or GREEN
Modem connection; Request To
Send(RTS); No Clear To Send(CTS)
AMBER (blinking)
Traffic; Modem or console
connection
Table 26 HSIM-W6 ASYNC Console Connection Pinout
PIN Description
1 VT Receive Data
2 VT Data Terminal Ready (DTR)
4 VT Transmit Data
5 Ground
