Chapter 7: General Configuration Using Local Management
HSIM-W6 User’s Guide 153
IPX Configuration Screen
The IPX Configuration screen enables you to access the IPX General Config, IPX SAP, and IPX
RIP screens to configure the HSIM-W6 for IPX Routing and enable RIP routing or SAP routing on
the HSIM-W6.
Access the IPX Configuration screen, shown in Figure 63 , by using the arrow keys to highlight the
IPX option on the Router Setup screen and then pressing ENTER. The IPX Configuration screen
displays.
Figure 63 IPX Configuration Screen
IPX Configuration Fields
The following list describes each of the IPX Configuration screen fields.
IPX General Config — Use this field to access the IPX General Config screen and configure the
HSIM-W6 for IP routing.
IPX CONFIGURATION
IPX General Config
IPX SAP
RETURN
IPX RIP
HSIM-W6 Local Management Flash Image Version XX.XX.XX
