Chapter 9: Troubleshooting
HSIM-W6 User’s Guide 199
Table 27 HSIM-W6 ASYNC Modem Connection Pinout
PIN Description
1 Transmit Data
2 Data Carrier Detect (DCD)
3 Data Set Ready (DSR)
4 Receive Data
5 Ground
6 Data Terminal Ready (DTR)
7 Request to Send (RTS)
8 Clear to Send (CTS)
Table 28 HSIM-W6 WAN Link (LNK) LED States
LED Color State
Link (LNK)
OFF
WAN interface not configured or not
present
RED
No Link/Connection (Fault) on the
WAN interface
AMBER
Transmit (TX) and/or receive (RX)
traffic
GREEN Link and port is active
GREEN (blinking) Link and port is in standby
