Chapter 7: General Configuration Using Local Management
HSIM-W6 User’s Guide 143
IP Configuration Screen
The IP Configuration screen enables you to access the IP General Config and IP RIP screens to
configure the HSIM-W6 for IP Routing and enable RIP on the HSIM-W6.
Access the IP Configuration screen, shown in Figure 60 , by using the arrow keys to highlight the
IP option on the Router Setup screen and then pressing ENTER. The IP Configuration screen
displays.
Figure 60 IP Configuration Screen
IP Configuration Screen Fields
The following list describes each of the IP Configuration Screen fields.
IP General Config — Use this field to access the IP General Config screen and configure the
HSIM-W6 for IP routing.
IP RIP — Use this field to access the IP RIP screen and enable Routing Information Protocol
(RIP) routing on the HSIM-W6.
IP CONFIGURATION
IP General Config
IP RIP
RETURN
2012_09
HSIM-W6 Local Management Flash Image Version XX.XX.XX
