Chapter 7: General Configuration Using Local Management
126 HSIM-W6 User’s Guide
System Level Screen
The System Level screen displays the physical address (MAC address) of the HSIM-W6 and
allows you to set the following parameters:
• System Date
• System Time
• Host IP Address
• Subnet Mask
• Default Gateway
• Default Interface
Access the System Level screen ( Figure 54 ) from the Setup Menu screen by using the arrow keys
to highlight the System Level option and pressing ENTER. The System Level screen displays.
Figure 54 The System Level Screen
COM 1 Application: [LM]
SYSTEM LEVEL
System Date:
Host IP Address 000.000.000.000
Subnet Mask 255.255.0.0
Phys Address 00-00-1D-16-26-F8
14:23:00 System Time:
SAVE RETURN
05/30/97
2012_04
Default Gateway NONE DEFINED
Default Interface NONE DEFINED
HSIM-W6 Local Management Flash Image Version XX.XX.XX
