Chapter 6: HSIM-W6 Configuration with QuickSET
HSIM-W6 User’s Guide 63
Local HSIM-W6 Subnet Mask — The Subnet Mask takes the same form as an IP address; four
groups of three decimal digits, separated by periods. Each group must be in the numerical range of
0 to 255. The first time you use QuickSET, the Subnet Mask field displays a default Subnet Mask,
based on the IP address entered, when it is clicked on. If you wish to use a different Subnet Mask,
enter it at this time in DDN format. A Subnet Mask must be entered in this field to continue.
Secondary IPs — The Secondary IPs window shown in Figure 20 displays after clicking on the
Secondary IPs... button, and shows the list of current Secondary IP addresses. The HSIM-W6 can
support multiple IP Subnets, therefore, there can be multiple Secondary IP Addresses assigned to
an Ethernet interface. To add a Secondary IP address, click on the Add IP button and enter the IP
Address, and Subnet Mask in their corresponding fields.
When you have finished making changes, click on the Apply Changes button. Click on the Done
button when you are finished.
Figure 20 Secondary IP Address List Window
