Chapter 7: General Configuration Using Local Management
HSIM-W6 User’s Guide 133
SNMP Traps Screen
The SNMP Traps screen allows you to configure the HSIM-W6 to send traps to as many as eight
remote management workstations. SNMP traps are messages about network events and device
operational statistics.
Access the SNMP Traps screen from the Setup Menu screen by using the arrow keys to highlight
the SNMP Traps option and press ENTER. The SNMP Traps screen, shown in
Figure 56 ,
displays.
Figure 56 The SNMP Traps Screen
Trap Table Screen Fields
The following definitions explain each of the SNMP Traps screen fields:
Trap Destination — Use this field to enter the IP address of the management workstation
designated to receive SNMP traps from the HSIM-W6.
Trap Community Name — Use this field to enter the maximum access level of SNMP traps that
will be forwarded to the Trap Destination.
SNMP TRAPS
Trap Community Name Trap Destination Enable Traps
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
public
public
public
public
public
public
public
public
(NO)
(NO)
(NO)
(NO)
(NO)
(NO)
(NO)
(NO)
SAVE RETURN
2012_06
HSIM-W6 Local Management Flash Image Version: XX.XX.XX
