Chapter 9: Troubleshooting
206 HSIM-W6 User’s Guide
WPIM-DDS Installed in HSIM-W6
The DDS circuit is Out of Service (OOS).
• Contact your WAN DDS Service Provider and have them test the operation of your DDS circuit.
Status (STS) LED is AMBER (blinking)
• Device is in test mode.
• The CSX400 is running its Power-up Diagnostic Tests.
• Loopback Testing is underway on a WAN circuit.
Status (STS) LED is GREEN
WPIM-SYNC Installed in HSIM-W6
The Port is operating normally; Request to Send (RTS) has been activated by your WAN device. If
it is not, use the following steps:
• Use QuickSET or Local Management to make sure that the WAN interface on the local device
is configured properly.
• Verify the cabling being used between the HSIM-W6 and the CSU/DSU.
WPIM-HDSL is Installed in HSIM-W6
The Port is operating normally, the WPIM is synchronized with the HDSL circuit at the remote
end.
WPIM-S/T is Installed in HSIM-W6
The Port is operating normally, ISDN BRI channel B1 or B2 or both are active.
