Chapter 9: Troubleshooting
200
HSIM-W6 User’s Guide
Table 29 HSIM-W6 WAN Status (STS) LED States for T1, DI, and E1 Ports
LED
Color
State
Status (STS)
OFF
Normal or disabled
RED
Red Alarm
AMBER
Yellow alarm
AMBER (blinking)
Port in test mode
GREEN
Request to send
Table 30 HSIM-W6 WAN Status (STS) LED States for DDS Ports
LED
Color
State
Status (STS)
OFF
Normal or disabled
RED
Not used
AMBER
Out of Service
AMBER(blinking)
Port in test mode
GREEN
Not used
Table 31 HSIM-W6 WAN Status (STS) LED States for SYNC Ports
LED
Color
State
Status (STS)
OFF
Normal or disabled
RED
Not used
AMBER
Not used
AMBER (blinking)
Port in test mode
GREEN
Request to send
