Chapter 4: Planning for HSIM-W6 ISDN Configuration
38 HSIM-W6 User’s Guide
Node Numbers —
Servers can have internal and external node numbers. The internal node
number is a logical number assigned by the system administrator to the server. The external node
number is the MAC address of the server. When adding SAP services to the SAP table, internal
node numbers are used.
Network Information Tables
The following tables list the items you need to define or obtain to configure the router. This
information is illustrated in the network information diagrams and described in the previous
sections. Worksheets are provided in
, so that you can enter details about your
HSIM-W6 and remote routers.
provides information for configuring your system settings,
explains the Remote Router Database configuration settings and
and routing configuration.
NOTE
To configure the HSIM-W6, you need to fill out one chart for the HSIM-W6 and one
Remote Router chart for each remote router to be entered into the remote router
database. If you are setting up both ends of the network, you need a mirror image of
the information listed below for configuring the router on the other end of the ISDN link.
Table 4 Configuring System Settings
Configuration Section
Item
Description
System Settings
Router Name
Name used to identify this router; sent to
other routers during PAP/CHAP security
authentication and displayed in the
Configuration Manager window.
Message
Message saved in the router to be read
by a system administrator; displayed on
the Configuration Manager main menu
window.
System Settings
Dial Authentication
Password
Dial Authentication
Password/Secret
This router’s password used for
authentication when the router dials out
to other routers or is challenged by them.
