2. Determine which end of the band will be the long end (end
extending almost completely up one side of the pipe). For cable
routing purposes, ADS recommends reserving the left side of
the pipe (upstream from the manhole) for the long end of the
band.
Note:
Position the edge of the band with the cable tie
holes (edge with small holes) facing downstream.
3. Determine the appropriate location on the band to mount the
Doppler velocity sensor, making sure the sensor will be both
above
the silt level and below the flow surface during minimum
flows.
If silt is not present, locate the sensor on the band so it will
be at the bottom center of the pipe once installed.
If silt is present, locate the sensor slightly up the long end
of the band so it will be above the silt level once installed.
4. Mount the sensor onto the inside of the band with two 4-40 x
5/16-inch
countersink screws, making sure the beveled end of
the sensor faces the upstream edge of the ring (edge opposite
cable tie holes). If holes do not exist on the band at or near the
desired mounting location for the sensor, drill holes in the band
using a 7/32-inch drill bit.
5. When applicable, mount the pressure depth sensor to the band
in the following way:
Mount the pressure depth sensor 2 inches to the left of the
Doppler velocity sensor. Make sure the sensor will be
underneath the flow once installed
.
Secure the pressure depth sensor to the band using two 4-
40 x 5/16-inch
countersink screws. If the sensor does not
have screw inserts, use two medium-sized cable ties to
secure the sensor to the ring. Crisscross the cable ties
across the top of the sensor and underneath the band.
6. Secure the sensor cables along the downstream edge of the long
end of the band according to the instructions in Securing the
Cables to the Band
on page 3-41.
