ADS Environmental Services FlowShark QR 775003 A2 User Manual
Page 84

Sensor Installation and Connection 3-27
Quantity
Description
ADS Part Number
1
IS Doppler velocity sensor with two 4-40 x
5/16-inch stainless steel screws
106194A–35 (ft)
as needed
IS velocity sensor extension cable
106135A–xxx
2
1
IS pressure depth sensor (0 – 5 psi) with two
4-40 x 5/16-inch stainless steel screws
3754-0001–40
3
(ft)
as needed
IS pressure depth sensor extension cable
106136A – xxx
2
1
replacement dryer tube
3704–0032
1
IS PC communication direct connection cable
106228A Rev H5
as needed
EMU serial cable
3800–0147
15
11-inch cable tie
I05–0003
25
4-inch cable tie
I05–0001
15
8-inch cable tie
I05–0002
10
anchor cable tie
I05–0004
15
¼-
× 2 ¼-inch anchor bolt (with 7/16-inch nut
and washer)
I01–0002
1
3/8-
× 2-inch stud
I01–0009
1
3/8-inch x 3-inch anchor bolt and nut
I01–0003
2
3/8-inch x 1-inch stainless steel hex bolts
I01–0001
4
3/8 – 16 stainless steel hex nuts
I15–0002
5
3/8-inch stainless steel flat washers
I55–0001
2
4-40
× 5/16-inch screw
I35–0001
8
6-32 washer
I55–0002
4
6-32
× 1-inch machine screw
I35–0004
4
6-32
× 5/16 inch nut
I15–0003
15
plastic push mounts
I01–0006
1
12-inch stainless steel mounting band
I25–0080
1
sliding ultrasonic plate
I25–0001
as needed
ultrasonic sensor surcharge mounting bracket
I40–0010
1
special predrilled 8-foot metal band
I40–0007
