3-6 ADS FlowShark IS Manual
Installing the Sensors in the Pipe
This section includes the procedures for performing sensor
installations using one of the following methods:

Standard Installations

Special Installations
Standard Installation
Performing a standard sensor installation involves the following
process:

Gathering the parts and supplies

Gathering the tools and equipment

Assembling the ring

Mounting the sensors on the ring

Securing the cables to the ring

Installing the ring in the pipe
Gathering Parts and Supplies
Obtain the following supplies before installing the ring and sensors
to prevent any costly delays. When ordering, specify the FlowShark
IS flow monitor ring-mounted installation hardware.
Quantity Description ADS Part Number
1 FlowShark IS flow monitor (includes internal
battery)
5000–IS1–US–01 1
1 monitor mounting bracket I40–0003
1 IS Ultrasonic Depth Sensor 106186A–35 (ft)
as needed IS Ultrasonic Depth Sensor Extension Cable 106137A–xxx 2
