2-4 ADS FlowShark IS Manual
ADS FlowShark IS Flow Monitor
The FlowShark IS flow monitor is a waterproof, airtight,
cylindrical, marine-grade aluminum canister housing a chassis
securing multiple printed circuit boards and a portable power source
(when applicable). The one-piece internal chassis, attached to the
inside of the monitor lid, provides a mounting surface for the
following boards:

Digital Signal Processor Board

Analog Board supporting Ultrasonic, Pressure, and Velocity

Voltage to Frequency Board

Voltage Regulator Board
FlowShark IS flow monitor with chassis (left) removed from enclosure (right)
The following FlowShark IS monitors are available through ADS:
Part Number Description
5000-IS1-US-01 With Internal Battery
5000-IS1-US Without Internal Battery
5000-IS1 For EU without Internal Battery
5000-IS1-01 For EU with Internal Battery
