Specifications A-7
IS PC Communication Interface Cable
(106227A–xxx, where xxx represents length)
Size Jacket - 0.318 inches (8 mm) in outside diameter
Construction 8- to 20-gauge and 4- to 18-gauge conductors
inside heavy-gauge polyurethane direct-burial
jacket
Connections Factory-fitted, potted connector on monitor end;
field-terminated strip connection at EMU
Length Maximum 300 feet (91.4 m)
Intrinsically-Safe Sensors
IS Ultrasonic Depth Sensor (106186A-30)
Housing Marine-grade aluminum/epoxy
Dimensions 7.13 inches (18.11 cm) long x 4.20 inches (10.67
cm) wide x 0.86 inches (2.19 cm) high
Accuracy 0.125 inches (3.2 mm)
Deadband Less than 1 inch (25 mm)
Frequency 40 kHz
Range 0.5 inches to 12.5 feet (1.27 cm to 3.8 m)
Resolution 0.01 inches (0.25 mm)
Drift 0.0 inches
Cable Standard size: 30 feet (9.1 m) long x 0.50 inches
(13 mm) diameter OD polyurethane jacket
Extension cables available up to 300 feet (91.4 m)
