A-6 ADS FlowShark IS Manual
Antenna Hi-Gain Center-fed Capacitive Monopole
Protocol TCP/IP
Addressing Fixed address through AT&T Custom APN
Network Attach Refreshed every 4 hours through hard-reattach
Communication Interface Board (106124D)
Protection BASEEFA-approved optoisolators, current-
limiting resistors, and agency-approved fusing
Construction Inside EMU enclosure in plastic sub-enclosure
ADS Power Supply (5000-0727)
Size 5.1 inches (13 cm) x 5.1 inches (13 cm) x 5.1
inches (13 cm)
Material Polycarbonate
Rating NEMA 4X
Mounting Panel mounting via four 0.175-inch holes
Input Voltage 100-240VAC, 50/60Hz
Output Voltage 12V DC, 1.2A
Connection AC: Supplied 6-foot line cord (U.S.) or hardwire
to AC input terminals
DC: Hardwire to DC output terminals
