BCR/BCR
1.3 GEO/GEO
1.3 EDGE/EDGE
1.3 AREA/AREA1.3 OMNI/OMNI
1.3 OMNI
Color ProII/ProII
1.3 ProII Color
No No No No Yes Yes Yes Yes
Coordinate Tool Input Tab
Coordinate Tool Inputs
Tool List Filter
The Tool List Filter helps to limit the input data available for x,y coordinates and angle data. From the drop-down,
select either of the following:
• Absolute—this is the default, and enables x and y location data as well as angle information from any tools that
provide this data.
• Offset Only—which enables the selection of location offsets of x and y coordinates and angle data from location
tools.
Banner Engineering Corp. Minneapolis, MN USA 260
2/2010 PresencePLUS Software Tools
