Communication Tool Exportable Results: Average Color Tool
Description Value Data Label
User-defined name string Tool Name
1 = Tool executed successfully
0 = Tool did not find a point to use as a reference
1 or 0 Success
Tool processing time for the current inspection. ms Execution Time
Fastest recorded tool processing time since the start of the inspection or
since power-up. ms Execution Time Min
Slowest recorded tool processing time since the start of the inspection or
since power-up. ms Execution Time Max
Communication Tool Exportable Results: Color Blob Tool
Description Value Data Label
User-defined name string Tool Name
1 = Tool overall results passed.
2 = Tool overall results failed.
1 or 0 Success
Tool processing time for the current inspection. ms Execution Time
Fastest recorded tool processing time since the start of the inspection or
since power-up. ms Execution Time Min
Slowest recorded tool processing time since the start of the inspection or
since power-up. ms Execution Time Max
Threshold
Threshold Min
Threshold Max
Count
Areas
Total number of pixes in all the color Blobs. pixels Total Area
Number of pixels in the largest color Blob. pixels Largest Blob Area
Centroid of the largest color Blob. pixels (X, Y) Largest Blob Location
Number of pixels in the smallest color Blob. pixels Smallest Blob Area
Centroid of the smallest color Blob. pixels (X, Y) Smallest Blob Location
Locations
Communication Tool Exportable Results: Color Match Tool
Description Value Data Label
User-defined name string Tool Name
