Description

Values

Option Name

This option is a mechanism for
adding characters after a string of
data.

User-defined ASCII characters (limit
of 75 characters)

End String

Note: ASCII Hex characters are
allowed. Special symbols such
as \r, \n, and \t will cause a
carriage return, new line, and tab
to be output repsectively.

Check this box to add a label to the
data before the data itself. Example:

Parameter labels

Enable Labels

Dark Count = 3, where "Dark
Count=" is the label.

4. Set conditions for conditionally exporting the selected data (in the Output Filter field).

• Select Pass to export the selected information on a passing Test tool.

• Select Fail to export the selected information on a failing Test tool.

Communication Tool Exportable Results

The Communication tool sends out the data in the same sequence that the tools appear in the inspection, and the result
of transmitting this data will increase the inspection time.

The following shows the data sent out for each Communication tool.

Description

Value

Result

Checks the connection (Ethernet only).

1 = The connection is valid, and data
will be sent.

Success

Processing time for the Sensor to send
the data out.

Given in ms.

Execution time

The table below shows the format of the data.

Example
