Banner PresencePLUS P4 COLOR Series - Manual (Page 252)

Description Value Data Label
Centroid of the largest Blob. pixels (X, Y) Largest Location
Number of pixels in the smallest Blob. pixels Smallest Blob Area
Centroid of the smallest Blob. pixels (X, Y) Smallest Location
Communication Tool Exportable Results: Edge Tool
Description Value Data Label
User-defined name string Tool Name
Tool processing time for the current inspection. ms Execution Time
Fastest recorded tool processing time since the start of the inspection
or since power-up. ms Execution Time Min
Slowest recorded tool processing time since the start of the inspection
or since power-up. ms Execution Time Max
Total number of bright-to-dark edges. whole number Bright-to-Dark Count
Total number of dark-to-bright edges. whole number Dark-to-Bright Count
Total number of all edges. whole number Total Edge Count
X, Y coordinates of all the edges found. pixels (X, Y) Location(s)
Communication Tool Exportable Results: Geometric Count Tool
Description Value Data Label
User-defined name string Tool Name
1 = Tool executed successfully
0 = Tool did not find a point to use as a reference
1 or 0 Success
Tool processing time for the current inspection. ms Execution Time
Fastest recorded tool processing time since the start of the inspection or
since power-up. ms Execution Time Min
Slowest recorded tool processing time since the start of the inspection or
since power-up. ms Execution Time Max
Total number of patterns above the minimum acceptance leval and below
the maximum number of patterns. whole number Match Count
X, Y coordinates of the point from ROIs will rotate. pixels (X, Y) Rotation Origin
Rotational value of the first pattern found. degrees Match Rotation
X, Y coordinates of the first pattern found. pixels (X, Y) Best Match Location
Point
Percent match of the first patttern found. 20-100% Best Match %
Banner Engineering Corp. Minneapolis, MN USA 252
2/2010 PresencePLUS Software Tools
