Models PPSIM.. Sensor Interface Modules
DC-Powered Interface for PresencePLUS ® P4 Sensors
Features
• Low-cost interface between user’s hardware and PresencePLUS P4 sensors
• Available with two methods for connecting to sensor, depending on model:
- 13-pin terminal strip for cordset with flying leads
- DB-15 connector for model P4C..SIM cordsets (see Cables on page 4)
• Available in current sinking (NPN) or current sourcing (PNP) output models
• LED indicators for sensor status and active outputs
• Integral External Trigger and Remote TEACH push buttons
• Easy-to-adjust 45° screw terminals for electrical wiring
• Built-in RS-232 serial port connector (DB-9, Female)
• Simple DIN-rail-mount or wall-mount configuration
Models
Models Output* Connections
PPSIM-NT
Current Sinking (NPN)
Two 13-pin Terminals
PPSIM-NC
One 13-pin Terminal
One DB-15 Connector
PPSIM-PT
Current Sourcing (PNP)
Two 13-pin Terminals
PPSIM-PC
One 13-pin Terminal
One DB-15 Connector
*NOTE: P4 Sensor output must be set to NPN mode when used with an NPN interface module. P4
Sensor output must be set to PNP mode when used with a PNP interface module. See the
System Setup window in the PresencePLUS GUI for output selections.
Model PPSIM..C
(DB-15 connection)
Model PPSIM..T
(Terminal strip connection)
Overview
The PPSIM.. series sensor interface module is a passive DIN-rail-mount or wall-mount
module. It enables remote external trigger and TEACH capability and provides remote
indication of sensor status for Banner PresencePLUS P4 Sensors.
