Kinetix 2000 Connector Data 59
AM, BM, and IM Input Specifications for TTL Encoders
AM, BM, and IM Input Specifications for Sine/Cosine Encoders
Feedback Power Supply
The IAM and AM power circuit board generates +5V and +9V dc for motor
and auxiliary feedback power. Short circuit protection and separate common
mode filtering for each channel is included.
Motor and Auxiliary Feedback Power Specifications
Parameter Description Min Max
AM, BM, and IM
On-state input voltage Input voltage difference between the plus (+) input and
the minus (-) input that is detected as an on-state.
+1.0V +7.0V
AM, BM, and IM
Off-state input voltage Input voltage difference between the plus (+) input and
the minus (-) input that is detected as an off-state.
-1.0V -7.0V
Common mode
input voltage Potential difference between any encoder signal and
logic ground.
-7.0V +12.0V
Current draw, dc Current draw into the + or - input. -30 mA 30 mA
AM, BM input
signal frequency
Frequency of the AM or BM signal inputs. The count
frequency is 4 times this frequency, since the circuitry
counts all four transitions.
— 5.0 MHz
IM pulse width
Pulse width of the index input signal. Since the index is
active for a percentage of a revolution, the speed will
determine the pulse width.
125 nS —
AM, BM phase error
2.5 MHz line frequency Amount that the phase relationship between the AM
and BM inputs can deviate from the nominal 90°.
-22.5° +22.5°
AM, BM phase error
1 MHz line frequency Amount that the phase relationship between the AM
and BM inputs can deviate from the nominal 90°.
-45° +45°
Parameter Description Min Max
Sine/cosine
input signal
frequency
Frequency of the Sine or Cosine signal inputs. — 250 kHz
Sine/cosine
input voltage Peak-to-peak input voltages of the Sine or Cosine
inputs.
0.5V (p-p) 2.0V (p-p)
Supply Reference
Voltage
Total Current
(1)
(1) Total current is for both channels, and is independent of usage by the other channel.
Min Nominal Max
+5V dc EPWR_5V 4.93 5.18 5.44 300 mA
+9V dc EPWR_9V 8.30 9.10 9.90 350 mA
