Contactor ratings, Transformer specifications for control power input, Multip – Rockwell Automation 2093-xxxx Kinetix 2000 Multi-axis Servo Drive User Manual User Manual
Page 159
Publication 2093-UM001A-EN-P — March 2007
Specifications and Dimensions
159
DC Common Bus Fuse Specifications
Contactor Ratings
The table below lists the recommended contactor ratings for integrated axis
modules installed without a line interface module.
Transformer Specifications for Control Power Input
Catalog Number
DC Common Bus
(1)
(1)
Fusing of dc common bus is independent of main input power configuration.
Bussman Fuse
Ferraz Shawmut Fuse
2093-AC05-MP1
N/A A50P20-1
2093-AC05-MP2
2093-AC05-MP5
Catalog Number
Main Input Power
AC Coil Contactor
DC Coil Contactor
2093-AC05-MP1
170...264V ac
single-phase
N/A N/A
2093-AC05-MP2
2093-AC05-MP5
2093-AC05-MP1
170...264V ac
three-phase
100-C23x10 100-C23Zx10
2093-AC05-MP2
2093-AC05-MP5
Attribute
Value (23V system)
Input volt-amperes
500VA
Input voltage
230V ac
Output voltage
200...240V ac
