Publication 2093-UM001A-EN-P — March 2007
Chapter
6
Configure and Startup the
Kinetix 2000 Drive System
Introduction
This chapter provides procedures for configuring your Kinetix 2000 system
components with your Logix SERCOS module.
System Configuration
Requirements
Configuration of a Kinetix 2000 system requires these products as a minimum.
Configure the IAM/AM
Follow these steps to configure the IAM/AM.
1. Verify that there is no power applied to the IAM/AM and that the
SERCOS fiber-optic cables are plugged into the Tx and Rx connectors.
To verify your fiber-optic cable connections, refer to Connecting Your
SERCOS Fiber-optic Cables on page 99.
Topic
Page
Configure the Logix SERCOS Interface Module
Apply Power to the Kinetix 2000 Drive
Product Catalog
Number
Version
RSLogix 5000 software
9324-RLD300NE
16.0 or later
RSLinx 0355-RSLETENE
2.50.00
or
later
SERCOS Interface Card Firmware
1756-MxxSE
16.20 or later
1756-L60M03SE 16.03
or
later
1768-M04SE 16.03
or
later
1784-PM16SE not
released
To configure
Begin with
The integrated axis module (IAM)
Step 2
An axis module (AM)
Step 4
