ULTRA Master Installation
Miscellaneous Files
The readme File
A file, titled README, may be included in the ULTRA Master
directory. This file contains installation instructions, change notes
from previous revisions, and information that became available after
this manual was printed. After you install ULTRA Master you can
access this file by choosing the Read Me icon in the ULTRA Master
window or by using Microsoft Write or an equivalent application
program to view the file
readme.wri
in the directory path where
ULTRA Master is installed.
Firmware Files
Firmware files are supplied in the Miscellaneous directory on the
ULTRA Master diskette. The current revision level of drive firmware,
excluding the TouchPad firmware, is displayed in the Drive
Information window of ULTRA Master. The current revision level of
TouchPad firmware is displayed as part of the TouchPad initialization
when a TouchPad is connected to the drive.
The types of files and their functions are:
●
Firmware – Main Operating firmware for the drive
●
Boot Block – Drive Initialization firmware for the drive
