Appendix G
Specifications
Appendix G
Agency Approvals
UL and cUL UL 508C File E145959
CE mark Low Voltage Directive and
Electromagnetic Compatibility Directive
Certificate of Conformity from TUV Product Service
Environmental
Operating Temperature 0
o
C to 55
o
C (32
o
F to 131
o
F)
Storage Temperature -40
o
C to 70
o
C (-40
o
F to 158
o
F)
Humidity 5% to 95% non-condensing
Altitude 1500 meters (5000 feet)
Derate 3% for each 300 m above 1500 m (1000 ft. above
5000 ft.)
Vibration 10 to 2000 Hz @ 2g
Shock 15g 11 millisecond half sine
Dielectric Withstanding (Hi-Pot)
Main AC 1414 (1500) VDC for 1 minute, <5mA leakage current
NOTE : Metal Oxide Varistors (MOVs) between line and earth ground must be removed when testing.
Internal EMI filter capacitors require testing with DC Voltage.
Weight
1398-DDM-005, -005X 1.7 Kg (3.7 Lbs)
1398-DDM-009, 009X 2.05 Kg (4.5 Lbs)
1398-DDM-019, -019X 2.0 Kg (4.4 Lbs)
Motor Encoder Interface
Signal Output Power 5 Volts DC
Encoder Inputs A/B, Differential, 26LS33 input, 1 MHz (4 MHz Quadrature)
Maximum Signal Frequency, 1/T Low Speed Measurement
Thermostat Inputs Normally closed
Hall Inputs Single-ended, 5 Volt Logic
ABS Input 0 to 5 Volt, 10-bit
User Interface
Serial Port RS-232 or four wire RS-485,
1200 to 19200 baud
Status Display 3 Level LED
Addressing Software selected
Digital Inputs
Selectable (4) 12-24 Volt, Optically Isolated, Single ended, Active High, 4.5
mA nominal
ENABLE 12-24 Volt, Optically Isolated, Single ended, Active High, 4.5
mA nominal. Minimum ON time = 1.5 msec.
