A-6 Options and Accessories
Connector Kits
Connector kits provide the ability to construct custom length cables.
Kits are available for all ULTRA 100 Series connectors. Each kit
consists of the appropriate 3M connector with the corresponding
plastic backshell, and instructions.
Mating Connectors
The following connectors are listed solely to provide a cross-reference
of mating connectors for the J1, J2 or J3 connectors on the
ULTRA 100 Series drives. ULTRA 100 Series drive conformance to
the European EMC Directive is contingent on the use of Rockwell
Automation cables.
These connectors are not available from Rockwell Automation. Please
contact the manufacturer or a distributor for additional information.
Manufacturer phone numbers are: 3M 1-800-225-5373 and AMP 1-
800-522-6752
Connector Type Part Number
J1 50 pin mini D-shell, 24-30 AWG cable solder cup,
squeeze latch 9101-1476
J2 20 pin mini D-shell, 24-30 AWG cable solder cup,
squeeze latch 9101-1477
J3 26 pin mini D-shell, 24-30 AWG cable solder cup,
squeeze latch 9101-1478
J4 or J5 9 pin D-shell for RS-232 or RS-485 9101-1479
1398-DDM Mating Connector Mating Backshell Description
J1 AMP 2-175677-7 AMP 176793-7 50-pin Mini D Ribbon, 28-30 AWG, Insula-
tion Displacement, Plastic Backshell,
Squeeze Latch
3M 10150-6000EC
1
3M 10350-A200-00 50-pin Mini D Ribbon, 28-30 AWG, Insula-
tion Displacement, Metal Backshell,
Squeeze Latch
3M 10150-3000VE 3M 10350-52F0-008 50-pin Mini D Ribbon, 24-30 AWG, Solder
Cup, Plastic Backshell, Squeeze Latch
J2 AMP 2-175677-2 AMP 176793-2 20-pin Mini D Ribbon, 28-30 AWG, Insula-
tion Displacement, Plastic Backshell,
Squeeze Latch
3M 10120-6000EC
1
3M 10320-A200-00 20-pin Mini D Ribbon, 28-30 AWG, Insula-
tion Displacement, Metal Backshell,
Squeeze Latch
3M 10120-3000VE 3M 10320-52F0-008 20-pin Mini D Ribbon, 24-30 AWG, Solder
Cup, Plastic Backshell, Squeeze Latch
J3 AMP 2-175677-4 AMP 176793-4 26-pin Mini D Ribbon, 28-30 AWG, Insula-
tion Displacement, Plastic Backshell,
Squeeze Latch
3M 10126-6000EC 1 3M 10326-A200-00 26-pin Mini D Ribbon, 28-30 AWG, Insula-
tion Displacement, Metal Backshell,
Squeeze Latch
3M 10126-3000VE 3M 10326-52F0-008 26-pin Mini D Ribbon, 24-30 AWG, Solder
Cup, Plastic Backshell, Squeeze Latch
1. For use with MDR Hand Press Tool Kit, 3M part number 3829
