C-20 TouchPad Instructions
5v Fuse +5 VDC Fuse blown
not applicable to 1398-DDM-005, 1398-DDM-005X, 1398-DDM-009, 1398-DDM-009X, 1398-DDM-019
or 1398-DDM-019X
EncFuse Encoder Power Fuse blown
not applicable to 1398-DDM-005, 1398-DDM-005X, 1398-DDM-009, 1398-DDM-009X, 1398-DDM-019
or 1398-DDM-019X
MtrOvT Motor Thermostat Overtemperature
IPMFalt IPM Fault (Overtemperature/Overcurrent/Short Circuit)
IMLinBk Channel IM Line Break
BMLinBk Channel BM Line Break
AMLinBk Channel AM Line Break
BusOvV Bus Undervoltage
BusUndV Bus Overvoltage
IlglHal Illegal Hall State
SubIntr Unused Interrupt - sub processor
MainInt Unused Interrupt - main processor
ExsAvgI Excessive Average Current
OvSpeed Motor Overspeed
ExsFErr Excessive Following Error
MtrEnc Motor Encoder State Error
MstrEnc Auxiliary Encoder State Error
MtrThrm Motor Thermal Protection
IPMThrm IPM Thermal Protection
EnNoMtr No Motor Selected while enabling drive
MtrType Motor Selection not in Table
PersWrt Personality Write Error
ServWrt Service Write Error
CPU-
Comm CPU Communications Error
MtrOvt Motor Overtemperature
IPMFalt IPM Fault
ExsVErr Excess Velocity Error
Comutat Commutation Angle Error
Not
Homd Axis Not Homed
NOTE:
The Drive Status display is read-only. DrvEnab and DrvRdy indicate
that the drive is functional. The other displays indicate an error condition.
Table C.17: Drive Status List for TouchPad (continued)
Display Parameter
Table C.18: Input Flags Parameter List for TouchPad
Display Parameter
FltRst Fault Reset Input Flag
ENABLE Drive Enable Input Flag
