11-4 Maintenance and Troubleshooting
Error Codes
Error codes may be accessed by attaching either a PC with
ULTRA Master software or a TouchPad to the serial port (J5):
●
ULTRA Master displays errors in two windows: Fault H istory
and Display F ault Status ,
●
The TouchPad display errors in the DrvStat parameter under the
STATUS branch title.
Table 11.1: Troubleshooting Guide
Problem or Symptom Error
Code Possible Cause(s) Action/Solution
STATUS LED not lit No AC power Verify power (115/230VAC sin-
gle phase) is applied to the
drive.
Internal power supply mal-
function. Call factory
Motor jumps when first
enabled Motor encoder wiring error Check motor encoder wiring.
See Figure 6.38 on page 31
No Absolute signal at J2-16 Monitor Absolute signal at J2-
16.
Incorrect motor chosen in
personality module Select the proper motor in
ULTRA Master.
Digital I/O not working
correctly I/O power supply discon-
nected Verify connections and I/O
power source
Motor Overtemperature 04 Motor TS+ (J2-19) and TS-
(J2-20) pins open Verify TS+ (J2-19) and TS-
(J2-20) connections for conti-
nuity.
Motor thermostat trips due
to:
High motor ambient temper-
ature, and/or
Excessive RMS torque Operate within (not above) the
continuous torque rating for
the ambient temperature (40°C
maximum).
Lower ambient temperature.
IPM Fault 05 Motor cables shorted Verify continuity of motor
power cable and connector.
Motor winding shorted inter-
nally Check for short on R,S,T and
Gnd windings of the motor.
Drive temperature too high Check for clogged or defective
fan.
Ensure cooling is not restricted
by insufficient space around
the unit.
Operation above continuous
power rating Verify ambient temperature is
not too high (above 60° C).
Operate within the continuous
power rating.
Output short circuit or over-
current Drive has a bad IPM, replace
drive.
