TouchPad Instructions C-7
Displays
Text
A drive name longer than eight characters may require scrolling with
the Left,
, and Right, , arrow keys. Drive names may be up to 32
characters in length.
Flashing characters in the Modify mode display are the characters that
are active.
●
Change the cursor position and resolution using the and
keys. For example: If the Drv Name in the Modify mode displays
InFeed with the F flashing, pressing the key causes the first e
to flash.
●
Press the or keys to increment or decrement a character by
scrolling through the list of valid ASCII characters. For example,
If the Drv Name in the Modify mode displays
InFfed with the
lowercase f is flashing, pressing the key causes the flashing
character to decrement to e .
Numeric
Flashing characters in the Modify mode display are the numbers that
are active.
●
Change the cursor position and resolution using the or key.
For example: If the Over Spd in the Modify mode displays 5200
and 52 is flashing, pressing the key causes 520 to flash.
●
Press the or key to increment or decrement these numbers.
For example: If the Over Spd value is 5200 and 52 is flashing,
pressing the key causes the setting to increment by 100 rpm
each time the key is pressed.
●
Parameter values may not exceed the maximum or minimum
limits, regardless of the cursor position.
For example: If the SpeedWin setting is
5000 rpm and the
Maximum Speed in the motor table is 5200 , pressing the key
increases the parameter to 5200 (the upper limit), but pressing the
key decrements the parameter to 4000 .
The most significant digit is reserved when a parameter allows a
negative (-) setting or the parameter provides a list of possible
selections. The
or key toggles the minus sign.
List
The most significant digit is reserved for an active/inactive selection
marker when a parameter provides a list of possible selections.
