TouchPad Instructions C-11
Motor Table
Table C.2: TouchPad Motor Table Identification by Motor Series
Motor ID Motor ID Motor ID Motor ID
B14H1050 551 F-4030-Q-F 271 H-2005-K-F 276 H-4075-R-F 282
B14H1056 558 F-4030-Q-H 15 H-2005-K-H 20 H-4075-R-H 26
B14H1060 560 F-4030-Q-J 527 H-2005-K-J 532 H-4075-R-J 538
B14H1066 562 F-4030-Q-K 783 H-2005-K-K 788 H-4075-R-K 794
B14J1050 559 F-4030-Q-L 1039 H-2005-K-L 1044 H-4075-R-L 1050
B14J1060 563 F-4030-Q-M 1295 H-2005-K-M 1300 H-4075-R-M 1306
B18H1070 564 F-4030-Q-N 1551 H-2005-K-N 1556 H-4075-R-N 1562
B18H1076 566 F-4050-Q-F 259 H-3007-N-F 277 H-6100-Q-F 283
B18H1080 568 F-4050-Q-H 3 H-3007-N-H 21 H-6100-Q-H 27
B18H1086 570 F-4050-Q-J 515 H-3007-N-J 533 H-6100-Q-J 539
B18J1070 567 F-4050-Q-K 771 H-3007-N-K 789 H-6100-Q-K 795
B18J1080 571 F-4050-Q-L 1027 H-3007-N-L 1045 H-6100-Q-L 1051
B90H1015 557 F-4050-Q-M 1283 H-3007-N-M 1301 H-6100-Q-M 1307
B90H1025 561 F-4050-Q-N 1539 H-3007-N-N 1557 H-6100-Q-N 1563
B90H1035 565 F-4075-R-F 272 H-3016-N-F 278 H-6200-Q-F 284
B90H1045 569 F-4075-R-H 16 H-3016-N-H 22 H-6200-Q-H 28
F-4075-R-J 528 H-3016-N-J 534 H-6200-Q-J 540
F-4075-R-K 784 H-3016-N-K 790 H-6200-Q-K 796
F-4075-R-L 1040 H-3016-N-L 1046 H-6200-Q-L 1052
F-4075-R-M 1296 H-3016-N-M 1302 H-6200-Q-M 1308
F-4075-R-N 1552 H-3016-N-N 1558 H-6200-Q-N 1564
F-6100-R-F 273 H-4030-M-F 280 H-6300-Q-F 285
E-3618-E-F 297 F-6100-R-H 17 H-4030-M-H 24 H-6300-Q-H 29
E-3622-H-F 298 F-6100-R-J 529 H-4030-M-J 536 H-6300-Q-J 541
E-3626-L-F 296 F-6100-R-K 785 H-4030-M-K 792 H-6300-Q-K 797
E-3629-L-F 299 F-6100-R-L 1041 H-4030-M-L 1048 H-6300-Q-L 1053
E-3633-L-F 300 F-6100-R-M 1297 H-4030-M-M 1304 H-6300-Q-M 1309
F-6100-R-N 1553 H-4030-M-N 1560 H-6300-Q-N 1565
F-6200-R-F 274 H-4030-P-F 279 H-8350-S-F 286
F-6200-R-H 18 H-4030-P-H 23 H-8350-S-H 30
F-6200-R-J 530 H-4030-P-J 535 H-8350-S-J 542
F-6200-R-K 786 H-4030-P-K 791 H-8350-S-K 798
F-6200-R-L 1042 H-4030-P-L 1047 H-8350-S-L 1054
F-6200-R-M 1298 H-4030-P-M 1303 H-8350-S-M 1310
F-6200-R-N 1554 H-4030-P-N 1559 H-8350-S-N 1566
F-6300-R-F 275 H-4050-P-F 281 H-8500-S-F 287
F-6300-R-H 19 H-4050-P-H 25 H-8500-S-H 31
F-6300-R-J 531 H-4050-P-J 537 H-8500-S-J 543
F-6300-R-K 787 H-4050-P-K 793 H-8500-S-K 799
F-6300-R-L 1043 H-4050-P-L 1049 H-8500-S-L 1055
F-6300-R-M 1299 H-4050-P-M 1305 H-8500-S-M 1311
F-6300-R-N 1555 H-4050-P-N 1561 H-8500-S-N 1567
