A-4 Options and Accessories
Motor Power Cables
Diagrams and schematics for these cables are shown beginning on
page B-21 .
(1398-DDM-005, -009 and -019 require
Rev D or higher cable) 30 m (100 ft) 9101-1373-100
LD-Series and Y-Series Motors to J2 0.6 m (2 ft) 9101-1375-002
3 m (10 ft) 9101-1375-010
7.6 m (25 ft) 9101-1375-025
15 m (50 ft) 9101-1375-050
(1398-DDM-005, -009 and -019 require
Rev D or higher cable) 23 m (75 ft) 9101-1375-075
J2 to customer supplied connector (no connector) 3 m (10 ft) 9101-1380-010
7.6 m (25 ft) 9101-1380-025
15 m (50 ft) 9101-1380-050
(1398-DDM-005, -009 and -019 require
Rev C or higher cable) 23 m (75 ft) 9101-1380-075
(1398-DDM-005, -009 and -019 require
Rev C or higher cable) 30 m (100 ft) 9101-1380-100
Description Part Number
Description Part Number
Drive to 2000 or 3000 Motors (H- or S-Series) 3 m (10 ft)
7.6 m (25 ft)
15 m (50 ft)
23 m (75 ft)
30 m (100 ft) 9101-1381-010
9101-1381-025
9101-1381-050
9101-1381-075
9101-1381-100
Drive to 4000 Motors (F-, H- or S-Series) 3 m (10 ft)
7.6 m (25 ft)
15 m (50 ft)
23 m (75 ft)
30 m (100 ft) 9101-1382-010
9101-1382-025
9101-1382-050
9101-1382-075
9101-1382-100
1398-DDM-030 or 1398-DDM-075 to 6000 Motors
(F-, H- or S-Series) 3 m (10 ft)
7.6 m (25 ft)
15 m (50 ft)
23 m (75 ft)
30 m (100 ft) 9101-1383-010
9101-1383-025
9101-1383-050
9101-1383-075
9101-1383-100
1398-DDM-075 to 6000 Motors (F-, H- or S-Series)
NOTE: This cable is not CE marked
3 m (10 ft)
7.6 m (25 ft)
15 m (50 ft)
23 m (75 ft) 9101-2179-010
9101-2179-025
9101-2179-050
9101-2179-075
1398-DDM-150 to 6000 Motors (F-, H- or S-Series) 3 m (10 ft)
7.6 m (25 ft)
15 m (50 ft)
23 m (75 ft)
30 m (100 ft)
9101-1399-010
9101-1399-025
9101-1399-050
9101-1399-075
9101-1399-100
