Type HSW−16 HSW−12 HSW−10
Stroke ranges
Ĉ Working stroke [mm] 9 ... 15 15 ... 25 20 ... 35
Ĉ Angle stroke range [°] 80 ... 100 80 ... 100 80 ... 100
Max. permitted loading values of the guide
Ĉ Dynamic torque M
per
with
vertical operation and
observing the maximum work
load
*)
[Nm] 0.6 1.5 2.5
Ĉ Combined load M
x
/M
per
+ M
y
/M
per
+ M
z
/M
per
< 1
Ĉ Static torque M
o per
*)
in vertical operation for press−
fit and joining procedures
without dynamic loading
[Nm]
[Nm]
[Nm] M
oxper
= 3
M
oyper
= 2.6
M
ozper
= 3.5
M
oxper
= 8
M
oyper
= 8
M
ozper
= 12
M
oxper
= 16
M
oyper
= 20
M
ozper
= 25
Ĉ Combined load M
x
/M
ox per
+ M
y
/M
oy per
+ M
z
/M
oz per
< 1
*) The torques apply to the centre of the guide carriage
Max. permitted loading with external drive
Axial force on
drive shaft F
Yper
[N] 10 18 30
Radial force on
drive shaft F
Zper
[N] 30 45 75
Drive torque M
Yper
[Nm] 0.85 1.25 2.5
Repetition accuracy [mm] ±0.02
Vibration Tested according to DIN/IEC 68/EN 60068
Part 2−6: severity class 2
Shock Tested according to DIN/IEC 68/EN 60068
Part 2−27: severity class 2
