HSW−...−AP/A S
Festo HSW−...−AP/AS 0812b English
59
13 Technical specifications
Type HSW−10 HSW−12 HSW−16
Model HSW Handling module
HSW−...−AP Ĉ with pneumatic swivel drive
(double−acting swing wing)
HSW−...−AS Ĉ without drive
HSW−...−AW Ĉ with aktive waiting position
HSW−...−SD Ĉ with protective cover
Installation position As desired (vertical operation preferred)
Medium Filtered, lubricated or non−lubricated comĆ
pressed air (grade of filtration min. 40 Ģm
Permissible operĆ
ating pressure HSW−...−AP [bar] 4 ... 8
Pneumatic connection M3 M5 M5
Permitted temperature range [°C] 0 ... +60
Lubrication Linear guide with service life lubrication,
re−lubrication recommended after 10
million strokes.
End position adjustment Adjusting screws for angle stroke range
Stop screws in working stroke direction
End−position
cushioning HSW−...−AP With shock absorber
cushioning
HSW−...−AS With rubber buffer (only for silencing)
Permitted shock absorber energy
Ĉ E
max
HSW−...−AP [Nm] 0.8 1 2
Ĉ E
hmax
HSW−...−AP [Nm] 2 10 15
Min. permissible pulse time
Pulse time t
t
= positioning time t
+ dwell time t
e
(definition see chapter 7)
[s] 0.6 0.8 1
