HSW−...−AP/A S
Festo HSW−...−AP/AS 0812b English
48
Please note
For HSW−...−AS with electric motor:
Movement to a fixed stop creates impulsive loadings in the drive train. This can
cause damage to the gears, for example.
S Always use reduced energy during reference runs to the fixed stops
(āā 1āā/ā9 in Fig. 1).
The rubber buffers in the fixed stops are only for silencing.
Please note
For HSW−...−...Wā:
S Please observe the warnings and instructions in the brief description for
BAW−HSW.
S Pressurize the add−on components.
S If necessary, carry out a separate test run to check that the add−on compoĆ
nents are functioning correctly.
Attachment
components Tests
Without work load Ĉ Check the correct assignment of the compressed air
connections
Ĉ Gripping speed
Ĉ Function of the proximity switches
With load Ĉ Check that the work load is gripped firmly
Fig. 22
S Pressurize the drive in one of the following ways as desired:
ć slow pressurization of one side
ć simultaneous pressurization of both sides with subsequent exhausting of
one side
Please note
The swivel module DSM for HSW−...−AP may only be operated unmodified as
supplied from the factory and with the protective cap (if present).
