Indirect Transfer:

You can indirectly transfer variables to a depth of four levels by
introducing extra hatch marks (#) before the variable number. In an
indirect transfer, a value is transferred to one variable via another.



At Block N204, the X-axis moves to 51.456. Example 1 shows single
indirection. The contents of variable #101 are used by variable #102.
The actual content of variable #102 is constant 101. The indirection
is activated at Block N204 by the addition of the (#) symbol to
variable #102.

Example 1:

N201

G90 G17 G71 G0

N202

#101 = 51.456

N203

#102 = 101

N204

X##102

Example 2:

N210

G90 G17 G71 G0

N211

#101 = 1

N212

#102 = 2

N213

#103 = 3

N214

#104 = 4

N215

#119 = 100

N216

LOOP 4

N217

#119 = #119 + 1

N218

#120 = 119

N219

X###120

N220

END

N221
