104 6 Conversational Editing
6.1 Con
v
ersational Pr
ogr
a
mming
Program Edit buttons
 When editing a program, these edit buttons are available.
Button Function
Abs/Inc toggles between Absolute, and Incremental
mode.
Milling activates the bottom menu bar for e.g.
Rapid, Line, Arc.
More Milling opens the menu for additional milling
operations e.g. Offset, Plane, Feed.
Delete Block deletes a single block located at the
cursor.
Drill Cycles opens the menu to select the type of
drill cycle that is to be defined.
Pocket Cycles opens the menu to select the type of
pocket cycle that is to be defined.
Other Cycles opens the menu to select other types
of machining operations that is to be defined.
Edit Features activates the bottom menu bar for
editing features; e.g. Find, Mark, Copy.
Exit exits the Program Edit feature.
