Setting up the Tool Table
To setup the Tool Table:
 Select the Setup button. The CAM Setup dialogue opens.
 Touch the right arrow key in the CAM Setup dialogue until the
Tool Table tab appears.
 Select the Tool Table tab. The Tool Table opens in the CAM Setup
dialogue.
 Touch inside a parameters field to enter a parameter.
 Enter parameter value.
 Touch the Enter button.
 Repeat steps 4 and 5 until all required parameters are entered.
 Select the Apply button to apply the changes without exiting or the
Use
button to apply the changes and exit the Tool Table.
Importing a Tool Table
To Import a Tool Table:
 Select the Setup button. The CAM Setup dialogue opens.
 Touch the right arrow key in the CAM Setup dialogue until the
Tool Table tab appears.
 Select the Tool Table tab. The Tool Table opens in the CAM Setup
dialogue.
 Select the Import button. The Import Tool Table File pop-up dialogue
opens.
 Browse to the location where the file you would like to import is
located and select it.
 Select the Ok button.
Exporting a Tool Table
To export a Tool Table:
 Select the Setup button. The CAM Setup dialogue opens.
 Touch the right arrow key in the CAM Setup dialogue until the
Tool Table tab appears.
 Select the Tool Table tab. The Tool Table opens in the CAM Setup
dialogue.
 Select the Export button. The Export Tool Table File pop-up dialogue
opens.
 Browse to the location where the file is to be saved.
 Type the name of the file to save in the File Name field.
 Select the Ok button.
Parameters highlighted in blue have been automatically
calculated. Calculations can be overridden by entering a
new value and touching ENTER.
