Tool Modification Programming Example:
This program mills the square shape four times. The 3500i executes
the first pass using the tool diameter entered in the Tool Page. Each
subsequent pass uses a different, "modified" tool diameter, as
programmed in Blocks 8, 10, and 12. T, D, L, and H are the only word
addresses allowed on the block.
Block #
Block
N1
O41 * TOOL-MOD.G
N2
G90 G70 G0 G17
N3
T0
N4
Z0
N5
X0 Y0
N6
T1 * .8000 DIA.
N7
M98 P1
N8
T1 D.6
N9
M98 P1
N10
T1 D.4
N11
M98 P1
N12
T1 D.2
N13
M98 P1
N14
T0
N15
G0Z0
