Cajun P550/P880/P882 Switch User Guide
Initialize and Setup of the P550/P880/P882 Switch
2-17
3. Refer to Table 2-5 and configure the other Console Port
Configuration dialog box parameters:
4. Click APPLY to save your changes, or CANCEL to clear your
selection.
Configuring the
Serial Console
Port as a TTY
Console Using
the CLI To configure the console serial port as a TTY Console using the CLI,
enter the following command:
set console type {tty|ppp}
Refer to the Cajun™ P550™/P880/P882 Command Line Interface
Reference Guide for Version 5.0 for details about this command.
Configuring the Serial Console Port as a PPP Console
You can reconfigure the serial port as a PPP console to support a
dial-in PPP connection using either the web agent or the CLI. Before
you can do so, however, you must connect a modem to the switch.
* Note: If you do not configure an IP address for the PPP serial
interface, the switch immediately sends the modem
configuration string. If you type TTY, you will re-access
the CLI login prompt.
Table 2-5. Console Port Configuration Dialog Box Parameters
Option Default Available Settings
Baud Rate 9600 300, 1200, 2400, 4800, 9600, 19200,
38400, 57600, 115200
Flow Control Xon/Xoff (TTY) None, Xon/Xoff (TTY)
Data Bits 8 7 or 8
Parity None Odd, Even, or None
Stop Bits 1 1 or 2
