Cajun P550/P880/P882 Switch User Guide
Configuring the OSPF Routing Protocol
11-27
7. Refer to Table 11-11 for an explanation of the LSA Detail
dialog box parameters.
Table 11-11. LSA Detail Dialog Box Parameters
Parameter Definition
Area Displays the 32-bit identifier of the area from which
the LSA was received.
Type Displays the link state type. Types include:
• Router Links
• Network Links
• Summary Network
• Summary AS Border
• AS External
• Multicast Group
• NSSA External
LS ID Displays the link-state ID. The link-state ID is an LS
type specific field containing either a router ID or an
IP address that identifies the piece of the routing
domain that is being described by the advertisement.
Router ID Displays the router ID of the originator of the link
state advertisement.
Sequence Displays the link-state sequence number. The
sequence number is a 32-bit signed integer.
Checksum Displays the checksum of the complete contents of
the advertisement, except the age field.
Age Displays the time (in seconds) of the LSA.
Link ID Displays the neighboring router’s interface ID.
Link Data Displays the interface ID of the associated router
interface.
Type Displays the link type of Router Network LSAs. Types
include:
• Point-to-point Link (1)
• Transit Network (2)
• Stub Network (3)
• Virtual Link (4)
TOS Count Displays the type-of-service count.
TOS 0 Metric Displays the type-of-service cost of the interface.
Network Mask Displays the network mask for the LSA.
