15-28
Chapter 15
Cajun P550/P880/P882 Switch Configuration Guide
2. Refer to Table 15-7 for information about the AppleTalk
Route Table parameters:
3. Click Delete Entries to remove selected route table entries.
Or
Click Flush Route Table to empty the route table of all
dynamic entries. Static and Local entries are not flushed.
Table 15-7. AppleTalk Route Table Parameters
Parameter Definition
Select Select the entry to be acted upon.
Network Range Displays the network range.
Metric Displays the AppleTalk metric for the network
range.
State Displays the state of the entry.The options include:
• Good
• Suspect
• Going Bad
• Bad
Owner Displays the AppleTalk component responsible for
the addition of the route.The options include:
• Local
• Static
• RTMP
Next Hop Displays the next hop address where forwarded
packets are routed.
Interface Displays the Appletalk interface associated with
the route table entry.
Zones Displays the zones associated with the selected
AppleTalk route.
