Cajun P550/P880/P882 Switch User Guide
Monitoring the Cajun Switch
17-11
3. Select the severity level to filter on a particular severity level
for events from the Severity Level field pull-down menu from
either dialog box.
4. Select an event to filter on a particular event type from the
Event Type field pull-down menu from either dialog box. The
event log entries open in the Event Log window
(Figure 17-8).
Figure 17-8. Event Log Dialog Box
5. Refer to Table 17-4 for a explanation Event Log window
parameters:
Table 17-4. Event Log Window Parameters
Entry Definition
Log ID Displays the number of this event in the log FIFO (First In
First Out).
Event ID Displays an index that identifies the event class.
Time Stamp Displays the date and time the event was recorded.
