12-24
Chapter 12
Cajun P550/P880/P882 Switch User Guide
Examine IPX Service Table Statistics
To examine the IPX service table statistics:
1. Select Service Table Statistics from the Routing > IPX >
Display web agent window. The IPX Service Table Statistics
dialog box opens (Figure 12-13).
Figure 12-13. IPX Service Table Statistics
2. Refer to Table 12-12 to review each statistic:
Source Method by which the service was learned. For example, SAP
or static.
TTL Number of seconds before the service expires.
Hops Number of routers (hops) that the packet must pass through
before reaching the network number associated with the
service.
Next-Hop
MAC Address MAC address of the next destination through which the
service is reached.
Table 12-11. IPX Service Table Parameters continued
Parameter Defines the...
Table 12-12. IPX Service Table Statistics Dialog Box
Statistic Defines the...
Current Number of
Services The current number of IPX services.
Peak Number of
Services The peak number of services.
Service Add Failures The number of failed attempts to add a
service to the routing table.
